The PT-MY series is a white-cabinet, box-type furnace that runs debinding and pre-sintering as one uninterrupted cycle. After a controlled low-temperature ramp removes the binder, the same chamber rises to pre-sintering temperature without moving the parts; a dedicated fume cabinet pulls burnout vapors out through a duct. Available in 1100 °C and 1300 °C grades, it is built for oxide and electronic ceramic green bodies where cracking, blistering, and binder residue must be avoided.
| Item | Detail |
|---|---|
| Model range | PT-MY1100 / PT-MY1300 |
| Chamber sizes (W × H × D) | 300×300×400; 400×400×500; 500×500×500; 600×600×600; 600×600×1200 mm; larger or custom dimensions on request |
| Temperature per grade | 1100 °C (resistance-wire heaters, Type N thermocouple) or 1300 °C (SiC rod heaters, Type S thermocouple) |
| Control performance | PID with self-tuning and multi-segment programming; ±1 °C holding accuracy |
| Hot-zone & shell | High-purity alumina-fiber chamber inside a double carbon-steel shell with forced air cooling; hinged front door |
| Process atmosphere | Ambient air standard; inert gas optional |
| Binder-vapor handling | Separate fume-treatment cabinet ducted to the furnace to extract decomposition gases |
| Safety & interface | Over-temperature / thermocouple-burnout / over-current cut-off, tower-stack alarm light, and a remote touch-screen enclosure with emergency stop |
