model:PT-V1600
Vacuum debinding and sintering furnace
Application: The vacuum debinding and sintering furnace is mainly used for the degreasing sintering process of cemented carbide, metal ceramics, stainless steel (nickel-based), iron-based, titanium alloy, alloy steel, high-speed steel and other metals.
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters of the Product
AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacIntroduction:AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacAQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere FurnacThe vacuum degreasing sintering furnace is a high-precision industrial thermal processing equipment integrating integrated degreasing and sintering functions. It features stable performance and wide material adaptability, capable of completing one-stop degreasing and densification sintering for various alloy and metal materials. It effectively removes internal binders and impurities, ensuring high density, high precision and stable mechanical properties of finished workpieces, which is widely favored in precision manufacturing industries.AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
ApplicationAQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The vacuum degreasing sintering furnace is professionally designed for integrated degreasing and sintering processes of various high-performance metal materials, including cemented carbide, cermet, nickel-based stainless steel, iron-based alloy, titanium alloy, alloy steel and high-speed steel.AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
It is widely adopted for precision processing and manufacturing of diverse sophisticated components. The applicable products cover medical and mechanical equipment parts such as orthodontic accessories and freight elevator sampling forceps, consumer electronic components including mobile phone metal decorative shells, navigation keys, card trays, fasteners, shafts and vibrator parts, as well as computer accessories and precision hardware tools.AQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
| Model |
Effective heating area sizeAQxMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
(width * height * depth/mm） |
Maximum temperature(℃) |
Ultimate vacuum(pa) |
Temperature uniformity(℃) |
Pressure rise rate(Pa/h) |
Loading capacity(kg) |
| PT-V1600-12W |
200*200*300 |
1600 |
≤5Pa |
±5 |
≤0.67 |
30 |
| PT-V1600-36W |
300*300*400 |
1600 |
≤5Pa |
±5 |
≤0.67 |
80 |
| PT-V1600-96W |
400*400*600 |
1600 |
≤5Pa |
±5 |
≤0.67 |
180 |
| PT-V1600-175W |
500*500*700 |
1600 |
≤5Pa |
±5 |
≤0.67 |
300 |
| PT-V1600-324W |
600*600*900 |
1600 |
≤5Pa |
±5 |
≤0.67 |
500 |
| PT-V1600-768W |
800*800*1200 |
1600 |
≤5Pa |
±5 |
≤0.67 |
800 |
