model:PT-JS557
Aluminum vacuum brazing furnace
Application: Application range of aluminum vacuum brazing furnace: vacuum brazing of non-ferrous metals, stainless steel, titanium alloy, high temperature alloy, cemented carbide, etc. ...
Contact us for customize
send-email:
info@lab-furnace.com
Detailed Parameters Of The Product
Description: Application range of aluminum vacuum brazing furnace: vacuum brazing of non-ferrous metals, stainless steel, titanium alloy, high temperature alloy, cemented carbide, etc. ...UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Application range: UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Vacuum brazing of non-ferrous metals, stainless steel, titanium alloys, high temperature alloys, hard alloys, etc.UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Product features:UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
1. Achieve high vacuum to ensure the quality of workpiece processingUitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
2. Heating elements are evenly arranged to ensure the uniformity of the furnace temperatureUitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
3. Metal molybdenum heating, stainless steel insulation, high furnace cleanlinessUitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
4. The touch screen interface is friendly and practical, and can display and Monitoring the operating status of the equipment, can call, edit and store the sintering process, and have dynamic display, historical data can be recorded and exportedUitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
5. Safety interlock, fault diagnosis and abnormal alarm functionUitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
UitMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technical parameters:
| Model |
PT-JS223 (optional) |
PT-JS334 (optional) |
PT-JS446 (optional) |
PT-JS557 |
PT-JS669 (optional) |
| Heating area (mm) |
200×200×300 |
300×300×400 |
400×400×600 |
500×500×700 |
600×600×900 |
| Heating power (Kw) |
25 |
50 |
75 |
95 |
150 |
| Maximum temperature (℃) |
1350 |
1350 |
1350 |
1350 |
1350 |
| Ultimate vacuum (Pa) |
10pa, 6.7×10-3pa |
| Heating element |
Metal molybdenum belt |
| structure |
Single indoor thermal horizontal structure |
| Heating rate |
0-20℃/min |
| More specifications can be customized according to requirements |
