| Main technical parameters | |
| Furnace structure | |
| Appearance | Adopt high-quality cold-rolled plate, which is precisely processed by CNC and other equipment and machine tools. The outer surface is treated with high-temperature spraying. It has an advanced air-cooled double-layer furnace structure. A fan is installed between the furnace shells, which can quickly increase and decrease the temperature and ensure a good working environment. |
| Appearance | Split type |
| Max. temperature | 1700 degrees |
| Working temperature | 1600 degrees |
| Chamber size | 200*200*300mm high |
| Thermocouple | Type B |
| Heating element | High-quality silicon molybdenum rod multi-faceted heating |
| Stirring function | 1. The height of the ceramic stirring rod is adjustable and can be moved up and down. 2. The ceramic stirring rod can rotate in both directions and the speed is adjustable. |
| Furnace bottom lifting | 1. The motor is used to drive the lifting to ensure the smooth lifting of the crucible 2. The top structure of the base is reasonably designed to ensure that the crucible is not easy to tip over during high-temperature stirring. 3. There is enough operating space after the base is lowered, which is convenient for manual placement of the crucible. 4. Open a late-stage flow hole at the bottom of the furnace and match it with a corresponding plug to prevent heat leakage when no material is left. |
| Electrical control part | |
| Microcomputer control | The temperature controller has PID adjustment and self-tuning functions. The current upper limit can be set manually, and multi-stage temperature rise and fall programs can be compiled. The intelligent temperature control instrument can be used for manual power adjustable temperature rise and fall. |
| Heating rate | 0℃-10℃/min adjustable |
| Temperature control protection | With over-temperature and broken couple protection functions |
| Refractory materials and furnace structure | |
| Inner cavity materials |
High-quality polycrystalline alumina fiber has special effects such as high temperature resistance, acid resistance, and oxidation resistance. It is not easy to crack, has a long service life, slow heat conduction, and energy saving. The unique furnace design is durable and will not collapse. |
| Insulation materials | Use high-quality ceramic fiber materials for insulation, high temperature resistance, low heat conduction, and no pollution. |
| Furnace structure | Reasonable and stable structure, high temperature resistance. |
| Others | |
| Warranty scope and period ● Warranty period | ●15 months from factory or 12 months after acceptance, whichever comes first (except for consumables such as silicon-molybdenum rods, silicon-carbon rods, resistance wires and man-made damage), lifetime warranty, free technical guidance installation and equipment commissioning services. After the warranty period expires, a renewal service is provided. ● General faults are resolved within 24 hours, and major faults are resolved within 72 hours. In special cases, technicians can go to the site to handle the problem. |
| Random accessories | 1 pair of high temperature resistant gloves. 1 set of base bricks. |
| Instructions for use | ● The electric furnace should be cooled slowly, and the recommended cooling rate is 10 °C/minute. ● It is forbidden to heat flammable and explosive substances or introduce flammable and explosive gases. ● After the electric furnace is used, small cracks will appear on the surface of the furnace lining. This is a normal phenomenon and does not affect the service life of the electric furnace. |
