| Model | PT A1100-432CZ |
| Display | LCD Touch Screen |
| Furnace Structure | •Double-layer steel structure with air cooling. •High purity Al2O3 fibrous insulation with Max. energy saving. |
| Max. Temperature | 1200℃ |
| Working Temperature | ≤1100°C ( continuous) |
| Heating Rate | 0~20℃/min ,≤10℃/min recommended |
| Inside Chamber Size(432L) | Depth 1200mm×Width 600mm×Height 600mm Can be customized according to customer needs |
| Loading | 300kg |
| Bottom load-bearing plate | Silicon carbide plate |
| Heating Element | External Resistance Wire With Mo |
| Heating Method | Heating on four sides |
| Thermocouple | N Type |
| Temperature Controller |
•LCD touch screen control with 16 temperature curves,each temperature curve can be automatically set with 30 steps programmable. •Built-in Over Temperature and Thermocouple Failure Protection. •Temperature Control Accuracy： +/- 1°C. |
| Chamber material | Alumina Fiber |
| Gas inlet and outlet | Stainless steel gas inlet with needle valve Stainless steel gas out let with needle valve and mechanical pressure gauge |
| Hand Wheel | To tight the door for better sealing in chamber. |
| Float Flowmeter | Standard flow range: 10-100ml/min for inert gas (Final flow range is based on customer’s requirement) |
| Vacuum pump | Two-stage vacuum pumps Ultimate vacuum degree -0.1Mpa (Empty furnace, cold state) |
| Automatic pressure relief | digital pressure gauge + solenoid valve |
| Warranty | One year limited warranty (Consumable parts such as heating elements and Thermocouple are not covered by the warranty) with lifetime support . |
| Power | About 74KW |
| Power supply | 440V three-phase 60Hz |
