model:PT-1700A

atmosphere heat treat furnace

Application

Contact us for customize send-email: info@lab-furnace.com

Detailed Parameters Of The Product

Description：
Atmosphere heat treat furnace is a kind of laboratory heat treatment furnace,it can protect materials from oxidation and decarburization with flowing nitrogen and other inert gases. Atmosphere furnace is widely used in all kinds of colleges and universities laboratory, chemical laboratory, industrial and mining enterprises for chemical analysis, physical measures, as well as metal, ceramic sintering, such as piece of small steel heating, calcination, heat treatment.

Outstanding features of atmosphere heat treat furnace :
1. Max. energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
2. Heavy duty double layer structure with cooling fan. Lower temperature in outside case.
3. PID automatic control via current limiting phase angle fired the resistor,e.g SCR (Silicon Controlled Rectifier)

We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!

Technical parameters of atmosphere heat treat furnace ：

Model	PT-1700A atmosphere heat treat furnace
Display	Touch screen
Max. temperature	1700°C
Working temperature	≤1600°C
Heating rate	Suggestion 0-20°C/min
Temperature accuracy	+/-1°C
Inside chamber	300×300×400mm
Heating element	MoSi2
Thermal couple	B Type
Temperature control	PID automatic control via SCR power control
Heating curves	30 steps programmable
Rated power	10KW
Working temperature	AC 110-480V 50-60Hz
Warranty	12 month (exclusive wearing part)
