model:PT-M1200

PT-M1200 64L Muffle Furnace

Application

Contact us for customize send-email: info@lab-furnace.com

Detailed Parameters Of The Product

Brief Introduction:
Protech PT-M1200 64L muffle furnace is mainly used for the high temperature sintering and annealing of materials.

The main features are as below:
1. High uniform temperature.
2. Easy to operate.
3. Over temperature protection and alarm

Technical Parameter:

Chamber Structure	Side Door
Display	LED
Max. Temperature	1200℃ for short time
Continuous working Temperature	≤1100℃
Heating Rate	Suggestion 0~10℃/min (Max. 20℃/min)
Inside Chamber Size	400×400×400mm (64L)
Heating Element	Resistance Wire with Mo
Thermocouple	K Type
Max. Power	16 KW
Working Voltage	AC380V three phases, 50 Hz (or according to your requirement)
Temperature Control	PID automatic control via SCR power control
Heating Curves	30 steps programmable
Chamber Material	Alumina Fiber
Warranty	One year limited warranty (Consumable parts such as heating elements are not covered by the warranty)
Standard Accessories	Crucible tong x 1 pair Protective glove x 1 pair
