Detailed Parameters Of The Product
Description:diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
The equipment is used for precious metal melting ,with a fast speed, low wastage, stable performance;adopted quartz crucible or graphite crucible, easy operation,especially for small amount gold ,Siliver , platinum, copper, aluminum,palladium melting ,This furnace suits for laboratory test use diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Features:diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
A. Light weight, small size and modular designdiJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
B. IGBT inversion technology, high-efficient conversion,LC series resonancediJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
C. Environmental protection,easy operation, low labor intensitydiJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
D. Melting rapidly, heating evenly, no oxide layer, and using timer to make sure diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
E. equipped with water cooling system(optional)diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
F. Cabinet or split type of aluminium melting Induction furnace for option.diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
diJMuffle Furnace,Tube Furnace,Vacuum Furnace,Atmosphere Furnac
Technicial Datas :
Model |
PT-C15KW |
Input Power |
15KW |
Output Current |
3-22 A |
Output Voltage |
70-550V |
Working Voltage |
220V |
Frequency |
1KHZ-20KHZ |
Work loading |
100% 24 hours |
Weight |
24KG |
Size |
27x45x46cm |
Cooling water demand |
>=0.2Mpa >=6/min |
Melting capacity |
1-2kg |
Melting time |
15 minutes per circle |
